Industrial standard
RS485 is a proven industrial communication standard known for its durability in noisy environments and long-distance data transmission.
WiSeNode-S Wireless FieldNode RS485-MODBUS-RTU
Advanced IoT Solution: In the era of Industry 4.0, where automation, efficiency, and data-driven decision-making are critical, the WiSeNode-S Wireless FieldNode RS485-MODBUS-RTU stands as a cutting-edge solution for industrial monitoring.
SKU: 5013.01167
Interested? Get in contact with us
Modular integration
Combined with the Modbus-RTU protocol, it provides a universal and efficient platform for data exchange, making it ideal for Industry 4.0 applications.
Empowering Businesses
Designed for industries that demand precision and reliability, it integrates advanced IoT technology seamlessly with user-friendly interfaces.
Product overview
The WiSeNode Wireless Field Module (RS485 Modbus RTU Master) enables seamless integration of Modbus-enabled sensors and industrial devices into the WiSeNode monitoring ecosystem. Designed for demanding industrial environments, the module collects data from connected RS485 Modbus RTU slave devices and transmits it wirelessly to the WiSeNode gateway and cloud platform for real-time monitoring and analysis. It forms a critical link between field instrumentation and actionable operational insight.
Core benefit:
This module enables secure wireless integration of Modbus RTU devices into the WiSeNode Industrial IoT ecosystem without redesigning existing infrastructure.
Key technical capabilities
Communication & Protocol
RS485 interface
Modbus RTU Master functionality
Support for multiple Modbus slave devices
Configurable baud rate and communication parameters
Wireless Connectivity
Long-range wireless communication (e.g., LoRa / LoRaWAN)
Energy-efficient data transmission
Reliable performance in distributed and remote environments
Data Handling
Local data acquisition and aggregation
Configurable polling intervals
Data buffering during temporary communication loss
Secure transmission to WiSeNode gateway
Industrial Hardware Design
Designed for industrial and infrastructure environments
Wide operating temperature range
Robust enclosure suitable for outdoor or cabinet installation
Industrial-grade power supply compatibility
Hardware Configuration
WSN-BB-S1 Node Core
WSN-EC-LORA1 LoRa radio module (up to 8 km line of sight)
WSN-ES-RS485 input board (Modbus RTU Master, 4 variables)
Integrated 3.7V 4500 mAh Li-ion battery
Mechanical & Environmental Specifications
Housing dimensions: 100 × 100 mm
Operating temperature range: −20 °C to +70 °C
Industrial-grade enclosure suitable for cabinet or outdoor installation
System Compatibility
Designed for use with the WiSeNode-XL Gateway
Compatible with WiSeNode Cloud platform
Typical Applications
Remote Asset Monitoring
Connect Modbus-based pressure, flow, temperature, or level sensors in remote installations and transmit data wirelessly to a centralized platform.
Legacy Equipment Integration
Integrate existing Modbus RTU equipment into modern IoT infrastructure without replacing installed hardware.
Distributed Infrastructure
Monitor geographically dispersed assets such as pumping stations, substations, or industrial installations.
Distributed Infrastructure
Monitor geographically dispersed assets such as pumping stations, substations, or industrial installations.
Integration within the WiSeNode Platform
The Wireless Field Module is not a standalone device, but a scalable component within a complete industrial monitoring architecture. It is designed to operate as part of the WiSeNode end-to-end monitoring architecture:
-
Measure
The module acquires precise data from connected RS485 Modbus RTU devices. Configurable polling intervals and local data handling ensure accurate and reliable field data collection, even in demanding industrial environments.
-
Transmit
Collected data is securely transmitted via long-range wireless communication to the WiSeNode gateway. Energy-efficient transmission and built-in buffering ensure continuity, even during temporary network interruptions.
-
Connect
Data is centralized within the WiSeNode Cloud platform, where it becomes accessible through real-time dashboards and structured data management. Users gain full visibility across distributed installations from a single interface.
-
Act
Once connected, data becomes actionable. Users can configure thresholds, automated alerts, trend analysis, and reporting functions to support operational decisions and proactive maintenance.
Interested? Get in contact with us.
Tell us about your application, integration requirements, or technical specifications. Our team will support you with expert guidance and help determine the right WiSeNode configuration for your environment.
